Audio System

X-SERIES 5-channel amplifier with 9-channel DSP and BT 24 Volt

Universally applicable

  • X-SERIES 5-channel amplifier with 9-channel DSP and BT 24 Volt
  • X-SERIES 5-channel amplifier with 9-channel DSP and BT 24 Volt, Thumbnail 2
  • X-SERIES 5-channel amplifier with 9-channel DSP and BT 24 Volt, Thumbnail 3
  • X-SERIES 5-channel amplifier with 9-channel DSP and BT 24 Volt, Thumbnail 4

Product number: 2104515

Manufacturer number: X-100.5 MDSP BT 24V

EAN: 4251834510586

€ 491,99

Incl. VAT
View product specifications

  • checkmark Free 30 days exchanges
  • checkmark Any part, any car
  • checkmark Fast delivery
  • checkmark Expert support

Ecommerce Europe Trustmark UPS

Customer service: +31 85 070 52 25

Ask your question at our product specialists.

Questions and answers.
Ask your question at our product specialists.
  • Specifications

    1. 5-channel amplifier with 9-channel DSP and BT
    2. APP software adjustable via ANDROID-BT or iOS-BT
    3. 9-channel SIGMA DSP processor from ANALOG DEVICES with automatic UPDATE via WLAN
    4. 30x parametric EQs per channel
    5. 8x presets up to 48 dB slope
    6. 4x DSP-controlled RCA outputs (5 volts)
    7. 6x RCA inputs (low level 0.5 to 4 volts)
    8. 6x Molex high-level inputs (up to 12V) via BTL or SE signal detection with automatic switch-on
    9. 1x remote output
    Frequency range: 10-24000 Hz
    Signal to noise ratio ADC: 107 dB and DAC: 112 dB
    Start/stop possible up to 18 volts/5 sec.
    Operating voltage 20-32 volts
    Operating temperature from -40 °C to + 85 °C

    • 4x 100 WRMS at 4 Ohms
    • 4x 140 WRMS at 2 Ohms
    • 1x 30 WRMS at 4 Ohms

    113 x 38 x 163 mm

    Suitable for:

    5-Channel

    Output590 Watt
    Number of channels5
    Warranty2 years
  • Applicability

    Universally applicable

  • Manufacturer

    Audio System
  • Delivery time

    Expected delivery date:

    28-05-2026
